英製管用斜度牙系列絲攻 PT
英制管用斜度牙系列(PT)
| Size 規格 |
Basic Diameter 基準外徑 mm |
Thread Length 螺紋有效長 mm |
Shank Diameter 柄徑 mm |
No. of Flutes 溝數 |
Overall Length 全長 mm |
Wedding焊接(W)/ Tungsten全鎢(T) | ||
| 1/16 | PT | 28 | 7.723 | 18 | 6.5 | 4 | 55 | T |
| 1/8 | PT | 28 | 9.728 | 19 | 8 | 4 | 55 | T |
| 1/4 | PT | 19 | 13.157 | 24 | 11 | 4 | 62 | T |
| 3/8 | PT | 19 | 16.662 | 24 | 14/22.225 | 4 | 65 | W |
| 1/2 | PT | 14 | 20.995 | 26 | 18/22.225 | 4 | 80 | W |
| 3/4 | PT | 14 | 26.441 | 26 | 23/22.225 | 4 | 85 | W |
| 1” | PT | 11 | 33.249 | 26 | 26/22.225 | 4 | 95 | W |
| 1”1/4 | PT | 11 | 41.910 | 30 | 32/22.225 | 4 | 95 | W |
| 1”1/2 | PT | 11 | 47.803 | 30 | 32 | 6 | 95 | W |
| 2” | PT | 11 | 59.614 | 35 | 32 | 6 | 95 | W |
| 2”1/2 | PT | 11 | 75.184 | 35 | 32 | 8 | 95 | W |
| 3” | PT | 11 | 87.884 | 35 | 32 | 8 | 95 | W |
找不到想要的規格?快點來電洽詢!
