美製管用牙系列絲攻 NPS/NPSM
美製管用牙系列(NPS/NPSM)
| Size 規格 |
Basic Diameter 基準外徑 mm |
Thread Length 螺紋有效長 mm |
Shank Diameter 柄徑 mm |
No. of Flutes 溝數 |
Overall Length 全長 mm |
Wedding焊接(W)/ Tungsten全鎢(T) | ||
| 1/8 | NPS NPSM |
27 | 10.242 | 19 | 8 | 4 | 75 | T |
| 1/4 | NPS NPSM |
18 | 13.572 | 24 | 11 | 4 | 62 | T |
| 3/8 | NPS NPSM |
18 | 17.055 | 24 | 14/22.225 | 4 | 75 | W |
| 1/2 | NPS NPSM |
14 | 21.223 | 26 | 18/22.225 | 4 | 85 | W |
| 3/4 | NPS NPSM |
14 | 26.568 | 26 | 23/22.225 | 4 | 85 | W |
| 1” | NPS NPSM |
11 1/2 | 33.228 | 26 | 26/22.225 | 4 | 90 | W |
| 1”1/4 | NPS NPSM |
11 1/2 | 41.985 | 26 | 32/22.225 | 4/6 | 90 | W |
| 1”1/2 | NPS NPSM |
11 1/2 | 48.054 | 26 | 32 | 6 | 90 | W |
| 2” | NPS NPSM |
11 1/2 | 60.092 | 35 | 32 | 6 | 95 | W |
| 2”1/2 | NPS NPSM |
8 | 72.699 | 35 | 32 | 8 | 95 | W |
| 3” | NPS NPSM |
8 | 88.608 | 35 | 32 | 8 | 95 | W |
| 3”1/2 | NPS NPSM |
8 | 101.316 | 35 | 32 | 8 | 95 | W |
| 4” | NPS NPSM |
8 | 113.973 | 35 | 32 | 8/10 | 95 | W |
| 5” | NPS NPSM |
8 | 104.952 | 35 | 32 | 10/12 | 95 | W |
找不到想要的規格?快點來電洽詢!
