Face Grooving Tools
| Order Number |
A Dia mm |
B mm |
R | C Length mm |
D Shake mm |
| B0601 | 1 | 3 | 0.1 | 50/100 | 6 |
| B0615 | 1.5 | 4 | 0.1 | 50/100 | 6 |
| B0620 | 2 | 5 | 0.1 | 50/100 | 6 |
| B0625 | 2.5 | 6 | 0.1 | 50/100 | 6 |
| B0630 | 3 | 6 | 0.1 | 50/100 | 6 |
| B0815 | 1.5 | 3 | 0.15 | 50/100 | 8 |
| B0820 | 2 | 5 | 0.15 | 50/100 | 8 |
| B0825 | 2.5 | 6 | 0.15 | 50/100 | 8 |
| B0830 | 3 | 6 | 0.15 | 50/100 | 8 |
| B1020 | 2 | 5 | 0.2 | 50/100 | 10 |
| B1025 | 2.5 | 6 | 0.2 | 50/100 | 10 |
| B1030 | 3 | 6 | 0.2 | 50/100 | 10 |
| B1035 | 3.5 | 8 | 0.2 | 50/100 | 10 |
| B1220 | 2 | 5 | 0.2 | 50/100 | 12 |
| B1225 | 2.5 | 6 | 0.2 | 50/100 | 12 |
| B1230 | 3 | 6 | 0.2 | 50/100 | 12 |
| B1235 | 3.5 | 8 | 0.2 | 50/100 | 12 |
| B1240 | 4 | 8 | 0.2 | 50/100 | 12 |
